OMG LP-15CF LP Coreless 7.4V 0.058sec 16.5kg (Black/Red/Violet)
Available in Black, Red and Violet color
Item No. OMG-LP-15CF
Operating voltage:4.8-8.4V
Operating speed:
6.0V-0.065sec/60°
7.4V-0.058sec/60°
Stall torque:
6.0V-15kgf.cm(208oz-in)
7.4V-16.5kgf.cm(229oz-in)
Gear Material:Stainless steel
Horn gear spline:25T Φ5.9
Size:41×20.5x29mm
Case Material:Top & middle cover in full metal ,bottom cover in plastic
Weight:60g
Bearing:2BB
Motor type:Coreless
Operating Temperature:-15℃~+70℃
Operating travel :≈180±10°
Neutral position :1520μsec
Frequency:1520uS
Refresh Rate:333Hz
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:180mm
Waterproof level:Dust & Water Splash Resistacne
Programmable:Yes
